| ITEM |
FULLY-AUTOMATIC
MICROHARDNESS TESTING SYSTEM
FM-ARS 9000 |
FULLY-AUTOMATIC
VICKERS HARDNESS TESTING SYSTEM
FV-ARS 9000 |
Standard
System
Component |
Analog Microhardness Tester Model: FM-100S
（OPTION： FM-300S、FM-800S available ） |
Analog Vickers Hardness Tester Model: FV-100S
（ OPTION： FV-300S、FV-800S available ） |
| Automatic X－Y Stage & Motor Drive Unit |
| CCD Camera |
| Complete set of PC： 17″Color CRT、Mouse、Keyboard、and Joy-Stick with Controller |
| Standard Software for System ARS 9000 |
| Ink-Jet Type Color Printer |
| PC： DELL or IBM Compatible Model with OS Windows XP |
| Micro Hardness Tester |
Model |
Model FM-100S： Stage Elevation Motor Built-in |
Model FV-100S： Stage Elevation Motor Built-in |
| Type |
Analog Type： Controllable Loading Operation by External PC |
| Test Load |
A： mN:98.07,245.2,490.3,980.7,1961,2942,4903, 9807 |
A： N:9.807, 19.61, 29.42, 49.03, 98.07, 196.1, 294.2, 490.3 |
| gf: 10, 25, 50, 100, 200, 300, 500, 1000 |
kgf: 1, 2, 3, 5, 10, 20, 30, 50 |
| B： mN: 49.03, 98.07, 245.2, 490.3, 980.7, 1961, 2942, 4903 |
B： N: 2.942, 4.903, 9.807, 29.42, 49.03, 98.07, 196.1, 294.2 |
| gf: 5, 10, 25, 50, 100, 200, 300, 500 |
kgf: 0.3, 0.5, 1, 3, 5, 10, 20, 30 |
| C： mN: 245.2, 490.3, 980.7, 1961, 2942, 4903, 9807, 19614 |
– |
| gf: 25, 50, 100, 200, 300, 500, 1000, 2000 |
– |
| D： mN: 9.807, 49.03, 98.07, 490.3, 980.7, 2942, 4903, 9807 |
– |
| gf: 1, 5, 10, 50, 100, 300, 500, 1000 |
– |
| Loading Mechanism |
Automatic Load/Hold/Rlease Method |
| Focus Operation |
Automatic / Manual Operation available
*Focusing Steps adjustable |
| Auto-Stage Elevation |
Automatic： by Built-in Stepping Motor
Manual： FM： by Standard Handle & Joy-Stick Operation / FV： by Joy-Stick Operation
*Safety Devices equipped to Overrun of Elevation. |
| Precision Vise |
Standard： Max. Opening: 50mm |
| Turret Roatation |
Automatic / Manual changeable |
| Load Appying Speed |
Initial Speed： 120μm/sec / Actial Loading Speed： 60μm/sec |
| Dwell Time |
5 － 40sec |
| Manual Occular |
( OPTION： Analog Type ) |
| Manual Measurement |
By Video Line on CRT available |
| Object Lens |
X10 / X50 (Optical Parts for 3rd Lens Built-in） |
X10 / X20 (Optical Parts for 3rd Lens Built-in） |
| Automatic Measurement Scale |
Vickers Hardness (HV) / Knoop Hardness (HK) |
| Automatic X-Y Stage |
Driving Motor |
Stepping Motor |
| Drive Control |
By Aicon： 2 Steps Speed available in X・Y・Z axis |
| Method |
By Joy-Stick： Flexible Speed Changing in X・Y・Z axis |
| Dimentions |
110 x 110mm |
| Max.Movement |
50 x 50mm in X・Y axis |
| Min.Movemetnt |
1μm |
| Moving Speed |
1 － 25mm/sec adjustable |
| Movement Program Pattern |
Straight Line (Horizontal & Vertical) / Zigzag / Circle / Arc /
Line Set for any Angle (8 Lines and Max. 3000 Indents on 1 Line) /
Random / Teaching / Matrix / Specificity of 2 Points / Specificity of Angle |
| Sample Profile Memory Function & Measurement along with Profile Line |
| Automatic Reading |
Pattern Setting |
Start Position Setting for Straight Line and Position Setting
for Random/Teaching Mode ahall be performed by Mouse-Click |
| Software |
OS: Microsoft Windows XP |
| Available Hardness Scale |
Vickers (HV) / Knoop (HK) |
| Measurement Repeatability |
±0.8% on Test Block 700HV/500gf |
±0.8% on Test Block 800HV/10kgf |
| Auto-Focus Time |
Shortest 3 sec |
| Auto Reading Time |
Approx. 0.2 sec/1 Indent |
| Measurable Min Indent |
5μm |
| Min Measurement unit |
0.1μｍ |
| Manual Measurement |
By OPTIONAL Occular or Video Line on CRT |
| Available Languages Support |
Japanese / English |
| Other Features |
Data Output Format & Editting Function |
Hardness Value, Hardness Chart, Case Depth, Insertion of Picture, etc. and Flexible Data Editing on “EXCEL” |
| Printer |
Standard: Color Ink-Jet Type |
| Joy-Stick |
For X・Y・Z axis Movement / Standard: Digital Type |
| Manual Occular |
OPTION： Analog Type |
| Safety Device |
Safety Devices equipped for Unmanned Operation
*Turret Rotation stop instantaneously in case of Object Lens or Indenter hit a Specimen.
*Upper & Lower Limit Stopper are equipped against Uncontrollable Stage Elevation |
