SprintMVP 624
Measurement Range (mm)
| Model |
X |
Y |
Z |
| SprintMVP624 |
624 |
624 |
200 |
Features
– Massive granite base for stability
– Moving bridge with stationary part, ideal for lage heavy parts.
– 0.5 micron scales on XY&Z standard
– Fully automatic – 3 axits joystick control
– High resolution digital color camera
– Motorized zoom lens system, 24X to 370X on screen digital/optical magnification standard with full feature Measure-X layout
– 12X tO 1470X on sceen digital/optical magnitificaton with optional add-on lenses and dual monitor user interface
– LED backlight, top light and high intensity ring light satndard
SPECIFICATION
| Measuring Unit |
624 |
| XYZ Travel, mm |
624 x 624 x 200 |
| XYZ Travel, in |
24 x 24 x 8 |
| System Dimensions, mm (XYZ) |
1425 x 1400 x 1655 |
| System Dimensions, in (XYZ) |
56 x 55 x 65 |
| System Weight, kg/lbs |
930/2400 |
