Engraving Tool 90°
- 10mm and 3/8" shank carbide toolholder with 60 and 90 degree engraving carbide inserts.
- Suitable mini spotting and 90 degree engraving.
- Each insert has 4 cutting edges.
Holder
For SW engraving using NC Spot Drill shank.
| STEP |
Part No |
Insert Size |
Ød |
L |
| |
99616-10 |
N9MT080201W |
10mm (0.394”) |
90mm (3.543”) |
| |
99616-3/8 |
N9MT080201W |
3/8" |
90mm (3.543”) |
Insert
• 60° & 90° Engraving tool, using standard holder of NC Spot Drill
- NC40 : For unhardened steel.
- NC10 : For non-ferrous metal & cast iron.
- Each insert has 2 cutting edges.
| Angle |
Part No |
Grade |
Coating |
Tmax. |
Wmin. |
Wmax |
Workpiece material |
| 90° |
N9MT080201W |
NC40 |
TiN |
0.9mm
(0.035”) |
0.2mm
(0.008”) |
2.0mm
(0.079”) |
PMK |
| 90° |
N9MT080201W |
NC10 |
TiAlN |
0.9mm
(0.035”) |
0.2mm
(0.008”) |
2.0mm
(0.079”) |
MKN |
| 60° |
N9MT080201W |
60-NC40 |
TiN |
0.8mm
(0.031”) |
0.2mm
(0.008”) |
1.1mm
(0.0433") |
PMK |
