Lưỡi dao khắc chữ Nine9

X060A30W020R

30 Degree X060 Engraving Tool

6mm (0.236”) carbide shank with 30 degree engraving carbide inserts.

•Each indexable insert has 2 cutting edges.
•Fine engraving 0.2mm (0.008”) bottom width with narrow angle 30°
•Full peripherally ground insert to ensure efficient repeatability.
•The latest coated carbide grades help you to obtain higher speed and feed rate, dramatically reducing your cycle time.
•One holder supports the entire X060 series of engraving inserts.
•Also using for deburring tool.

Holder

30 degree X060 carbide engraving cutter

Part No	Insert Size	Ød	L	Shank
99619-X060-06	X060 series	6mm (0.236”)	40mm (1.575")	Steel
99619-X060-06L	X060 series	6mm (0.236”)	60mm (2.362”)	Carbide
99619-X060-06LS	X060 series	6mm (0.236”)	60mm (2.362”)	Steel

Insert

30 degree X060 engraving carbide insert

• NC2032:
For all kinds of steel from < 40 HRC, carbon steel, alloy steel,and cast iron.
• NC2035:
ALDURA coating, reduces heat and tool wear.
For steel with heat treatment up to 56 HRC.
• XP9001:
Mirror polished, for non-ferrous metal, aluminum, brass, copper, plastic, acrylic.

Part No	Grade	Coating	Tmax.	Wmin.	Wmax	Re	R max. Depth	Workpiece material
X060A30W020R	NC2032	TiAlN	0.6mm (0.024")	0.2mm (0.008”)	0.74 (0.029")	0.04 (0.002")	-	PMK
X060A30W020R	NC2035	ALDURA	0.6mm (0.024")	0.2mm (0.008”)	0.74 (0.029")	0.04 (0.002")	-	PKH
X060A30W020R	XP9001	Polished	0.6mm (0.024")	0.2mm (0.008”)	0.74mm (0.029")	0.04mm (0.002")	-	N
X060A30R020_Radius form	NC2032	TiAlN	0.6mm (0.024")	-	0.84mm (0.033")	0.2mm (0.008”)	0.15mm (0.006")	PMK
X060A30R020_Radius form	NC2035	ALDURA	0.6mm (0.024")	-	0.84mm (0.033")	0.2mm (0.008”)	0.15mm (0.006")	PKH
X060A30R020_Radius form	XP9001	Polished	0.6mm (0.024")	-	0.84mm (0.033")	0.2mm (0.008”)	0.15mm (0.006")	N
